Saginaw Pipe Co. stocks ASTM A53 pipe, seamless and welded, for mechanical, pressure, and general construction work. As an A53 pipe supplier with more than 41 years of steel service center experience, we carry deep inventory across our Saginaw, Alabama, and Palmyra, Pennsylvania locations, ready to ship standard mill lengths or cut to your dimensions with mill test reports on every order.

ASTM A53 covers three manufacturing types and two mechanical grades. Knowing which combination a project needs keeps procurement fast and avoids costly substitutions.

Type F, Type E & Type S Explained

 Type F is furnace butt-welded, continuous-weld pipe, limited to smaller diameters and not approved for flanging. Type E is electric-resistance-welded (ERW) pipe, with Grade B seams heat-treated above 1,000degF to remove brittle weld structure. Type S is seamless A53 steel pipe, hot-worked from a solid billet with no weld seam. Saginaw Pipe's A53 inventory runs seamless and ERW.

Grade A vs. Grade B

Grade A carries a minimum yield of 30,000 psi and tensile strength of 48,000 psi. Grade B steps up to 35,000 psi yield and 60,000 psi tensile. Grade B's added strength makes it the standard for most mechanical piping, and the grade Saginaw Pipe carries. Need Grade A? Contact our team to source it.

ASTM A53 pipe holds to chemical limits of 0.25 percent maximum carbon for Grade A or 0.30 percent for Grade B, with manganese, phosphorus, and sulfur capped so mills hit the required mechanical properties. The spec covers nominal sizes from 1/8 inch through 26 inches, across wall schedules 10 through XXH. Every length ships plain-end, beveled, or cut to dimension in-house.

A53 Pipe Sizes Available

Saginaw Pipe stocks A53 pipe across the ASTM-covered range, from 1/8-inch NPS through 26-inch OD, in standard mill random lengths. Need a shorter or odd length? Our in-house cut-to-length service handles it, so you're not paying to ship material you'll cut down on-site.

A53 pipe is built for mechanical and pressure service:

• Steam lines
• Water and gas transfer
• Compressed air systems
• General framing where a full A500 structural tube is not required.

Saginaw Pipe supplies ASTM A53 seamless pipe and welded A53 for several industries, including:

• Agriculture
• Mechanical Contracting
• Highway Construction
• Conveyor Systems
• Oil & Gas
